VOX VE-TS Valvenergy Tone Sculptor Effects Pedal

Inputs/Outputs

INPUT terminal (monaural phone jack), OUTPUT terminal (monaural phone jack), DC.9V terminal

---

Frequency Adjustments

100Hz to 5.6kHz: ±10dB adjustment for each

LEVEL: ±12dB adjustment of the output volume.

---

Power Supply*

9V alkaline batteries (6LF22/6LR62) or DC.9V AC adapter (both sold separately)

*: The use of an AC adaptor is recommended as the unit’s power consumption is relatively high. Should you prefer to use batteries, please use the alkaline type.

---

Dimensions (W x D x H)

72mm x 120mm x 55mm (plug retracted/ VE-TS H:54mm)

---

Weight

300 g (excluding batteries)

---

Accessories

AC adapter KA181(9V) (sold separately)

---
